AVProEdge AC-EX70-444-KIT - Page 15

■
IR Connections to AC-EX70-444-T (Transmitter)
■
IR Connections to AC-EX70-444-R (Receiver)
IR INPUT
(Receiver Eye)
IR OUTPUT
(IR Emitter)
IR INPUT
(Receiver Eye)
IR OUTPUT
(IR Emitter)
*NOTE: For best results, only use the provided IR EYE's and Emitters
AC-EX70-444-KIT
Page 15
