ADVANCED OPERATION
17
*Pink blocks represent the area that is not being detected while the transparent blocks are the area under detection.
There are three detection areas for your choice:
Press “▲” or ” ◄” once to broaden the detection area.
Press “▼” or ” ►” once to narrow the detection area.
5.5. REMOTE
In this menu list, you can set up remote devices to work properly.
Move to “REMOTE”, and press ”ENTER”. You will see the following submenu items:
1) TITLE
Show the camera title of each channel set in “CAMERA”.
2) DEVICE
Select the device type (CAMERA / PTZ) according to the connected camera for each channel.
3) ID
Set the ID number (0 ~ 255) for a PTZ camera. After connecting to a PTZ camera correctly, the default ID of the
PTZ camera will be shown on the screen.
4) PROTOCOL
Select NORMAL (our protocol), P-D (PELCO-D) or P-P (PELCO-P) protocol.
5) RATE
Set the baud rate of each channel (2400 / 4800 / 9600 / 19200 / 57600 / 115200). For the connected cameras,
such as PTZ and speed dome cameras, etc., please make sure their baud rate setting is the same as the setting
here.
5.6. SYSTEM INFO
In this menu list, you can check or change some system settings.
The submenu items are described below:
1) SERIAL TYPE
Display the serial type of the DVR (RS485).
2) BAUD RATE
Set the baud rate of the DVR (2400 / 9600 / 19200 / 38400 / 57600 / 115200).
3) HOST ID
Set the ID of the DVR (0 ~ 254).
4) PASSWORD
Press “ENTER” to reset the password for accessing the DVR system. You can set the password up to 4 digits.
Note: Users who use guest password to access the DVR will be only allowed to view the live streaming
video and sequence display, shift the channel display, and lock keys.
