4MP WATER-PROOF TURRENT NETWORK CAMERA | AVC-ELN41FT_2.8
Step 3: Route and connect the cables and then secure the camera to the ceiling or wall with
the screws.
Step 4: Adjust the camera to obtain an optimum angle by loosening the fixed screws.
Before adjustment, preview the image of the camera on a monitor.
Step 5: Tighten the fixed screws after you finish adjusting the view angle of the camera.
Rubber Plug
Fixed Screw
