AC POWER
You can power your appliance by plugging the detachable AC power cord into the AC inlet at the
back of the appliance and into a wall AC power outlet. Check that the rated voltage of your appliance
matches your local voltage.
PHONO COVER ASSEMBLY
1. Push the metal bracket to rear side.
2. Connect the metal bracket to the phono cover.
3. Connect the hinge of the phono cover to the
appliance.
LOCATION OF CONTROL
POWER SOURCE
E-4
TURNTABLE HEAD
TONE ARM
SPEED SELECTOR
PLATTER
1
2
33
