TECHNICAL INFORMATION
connection type and the power rating of the cooker.
Caution !
All electrical work should be carried out by a suitably qualified and authorized electrician.
No alterations or willful changes in the electricity supply should be carried out.
Fitting guidelines
The cooker is manufactured to work with three phase alternating current (380-415V~50
Hz). The voltage rating of the cooker heating elements is 220-240V. Adapting the cooker
to operate with one phase current is possible by appropriate bridging in the connection
box according to the connection diagram below. The connection diagram is also found on
the cover of the connection box. Remember that the connection wire should match the
The fixing line connected must be equipped with the all-pole disconnection device
provided by breakaway the contact under overvoltage category III according to
the wiring rules.
Before connecting the cooker to the power supply it is important read the informatIion on
the data plate and the connection diagram.
Caution !
Remember to connect the safety circuit to the connection box terminal marked with
.
The connection cable must be secured in a strain-relief clamp.For the connection leads,
the grounding wire must be longer than the other wires.
CONNECTION DIAGRAM
C
aution! Voltage of heating elements 220-240V
C
aution! In the event of any connection the safety
W
ire must be connected to the E terminal.
R
ecommended
t
ype of
c
onnection
l
ead
1
L1
N
E
H
05VV-F3G 6
2
F
or 380-415/220-240V earthed three-phase-
connection, bridges connect 4-5 terminals,
phases in succession 1,2 and 3, earth to
4
-5, the safety wire to
.
NN E
L1L1
L2 L3
H
05VV-F5G1.5
L1=R, L2=s, L3=T, N=
Null T
erminal, E=safety wire terminal
1
2 3
4
For 220-240V earthed one-phase connecti-
bridges connect 1-2-3 on, terminals and
4-5 terminals, safety wire to
.
ELECTRICAL CONNECTION
A9062C
900/897/600
TYPE
Dimensions
(height/width/depth) mm
Oven
Top heater(kW)
Grill heater(kW)
Oven illumination(W)
Function modes
Electrical Input(V)
Oven power(kW)
180mm Hilight heater(kW)
145mm Hilight heater(kW)*2
220mm Hilight heater(kW)
250mm/145mm
Hilight heater(kW)
Cooktop
6
0.85
1.1
25
50-250℃
1.8
1.2
2.3
2.0/1.1
Guide levels
Bottom heater(kW)
Temperature
Frequency(Hz)
Hotplate power(kW)
Total main power(kW)
1.15
50
380-415V ~
3.0
8.5
11.5
220-240V/
Top+bottom heater(kW)
Top/grill(kW)
3.0
Bottom heater(kW)
Top+bottom heater+fan(kW)
Fan(W)
Fan+Rear heater(kW)
Fan+Half grill(kW)
Fan+Bottom heater(kW)
3.0
3.0
1.8
1.8
1.8
3.0
1.8
Half grill(kW)
60
