awave DSP 6V3 - 3 Dsp and Drc Installation; 4 Connection Panels-Description; Input Signals

PRODUCT BRIEF INTRODUCTION
[ 3 ]
PRODUCT BRIEF INTRODUCTION
[ 4 ]
3.DSP AND DRC INSTALLATION
ACC ON
AUTO ON
External dimensions
How to install
WARNING: do not use aggressive cleaning agents or abrasive cloth to clean the display.Simply use
a soft cotton colth lightly damped with water.
MAI N
160mm
224mm
49mm
BLUETOOTH
REMOTE
CONTROL
HIGH LEVEL INPUT
POWER + SPEAKER OUT
INPUT
OPTICAL
PRO
POW
FUSE
GND
+12V
4.CONNECTION PANELS-DESCRIPTION
4.1 Input signals
ACC ON
AUTO ON
MAIN
BLUETOOTH
REMOTE
CONTROL
HIGH LEVEL INPUT
POWER + SPEAKER OUT
INPUT
OPTICAL
PRO
POW
FUSE
GND
+12V
1-2-3-4-5-6
1 INPUT +
2 INPUT +
3 INPUT +
4 INPUT +
5 INPUT +
6 INPUT +
1 INPUT -
2 INPUT -
3 INPUT -
4 INPUT -
5 INPUT -
6 INPUT -
