5.2 Personal computer and Digital Remote Coontrol(DRC)
5.3 High-Level input signals
1.SPEAKERS IN HI-LEVEL STEREO FRONT+REAR+SUBWOOFER .
5.4 MAIN LEVEL INPUT
AMPLIFIED RADIO DECK
5.5 Low-Level ,BLUETOOCH input signals
AUX IN L/R: Auxiliary analog stereo sigal .
Sensitivity is adjusttable from 0.6 to 5V RMS .
BlueTooth IN :
Insert the Bluetooth control module into the DSP .
turn on your mobile phone and find the Bluetooth control mode.
Click on the Bluetooth . When the control mode is automatically
Paired successful . Then you can play the music.
DO NOT INSERT THE USB.
