3.DSP AND DRC INSTALLATION
External dimensions
How to install
WARNING: do not use aggressive cleaning agents or abrasive cloth to clean the display.Simply use
a soft cotton colth lightly damped with water.
4.CONNECTION PANELS-DESCRIPTION
4.1 Input signals
1-2-3-4-5-6
156.5mm
47mm
DSP6V4
224mm
2. OUTPUT; CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
