awave DSP6V4 - Output Signals; Personal Computer and Digital Remote Coontrol(DRC); High-Level Input Signals; Low-Level Input Signals

1 INPUT +
2 INPUT +
3 INPUT +
4 INPUT +
5 INPUT +
6 INPUT +
1 INPUT -
2 INPUT -
3 INPUT -
4 INPUT -
5 INPUT -
6 INPUT -
PRODUCT BRIEF INTRODUCTION
[ 7 ]
PRODUCT BRIEF INTRODUCTION
[ 8 ]
5.2 Personal computer and Digital Remote Coontrol(DRC)
5.3 High-Level input signals
1.SPEAKERS IN HI-LEVEL STEREO FRONT+REAR+SUBWOOFER .
5.5 MAIN LEVEL INPUT
5.6 Low-Level ,BLUETOOCH input signals
Sensitivity is adjusttable from 0.6 to 5V RMS .
BlueTooth IN :
Insert the Bluetooth control module into the DSP .
turn on your mobile phone and find the Bluetooth control mode.
Click on the Bluetooth . When the control mode is automatically
Paired successful . Then you can play the music.
DO NOT INSERT THE USB.
5.4 High-Level output signals
