Chapter 6: Programming Information A794 Owner’s Guide
December 1999120
Recognizing Data from the Printer
An application sending various Real Time and non-Real Time commands to which the
printer responds can determine which command a response belongs to by the table
below.
Responses to ESC u and ESC v are non-Real Time responses and will arrive in the order
in which they were solicited.
Batch Mode Response Response Recognized By:
1B 75 0 0 0 0 0 0 0 x x Binary
1B 76 0 0000xxxBinary
1D 49 n 0 xx0xxxxBinary
1D 72 n 0 xx0xxxxBinary
Real Time Response Response Recognized By:
1D 04 n 0 x x1xx10Binary
10 04 n 0 x x1xx10Binary
1D 05 1 x xxxxxxBinary
XON 0 0 010001Binary
XOFF 0 0 010011Binary
Auto Status Back (ASB) Response Recognized By:
ASB Byte 1 0 xx1xx00Binary
ASB Bytes 2-4 0 xx0xxxxBinary
