A794 Owner’s Guide Chapter 4: Print Specifications
December 1999 29
Print Zones for 82.5 mm Paper
Specifications of print zone for 82.5 mm paper:
♦
640 dots (addressable) @ 8 dots/mm, centered on 82.5 mm
♦
Standard mode: minimum margins: 1.0 mm (0.040 inches)
♦
Top margin to manual tearoff: 17.8 mm (0.70 inches)
♦
Top margin to knife cut: 19.0 mm (0.75 inches)
Cut Edge
48 Standard Columns = 78.0 mm (3.07 in.)
62 Compressed Columns = 77.5 mm (3.05 in.)
Cut Edge
Paper Width = 82.5 mm (3.25 in.)
Top Margin, 17.8 mm (.70 in.) Minimum
Printable Zone, 640 Dots = 80 mm (3.15 in.)
Nominal Margins (2) = 1.25 mm (0.05 in.)
To Next Page
