RTP120 All-in-One 12.1” TFT LCD Panel PC User’s Manual
System Configuration
14
2.1.4 30
o
Table Standing
For a 30
o
table-standing use, only the standard set of mounting kit is
needed, there is no pedestal kit or cable management shroud
required. The standard kit making up a 30
o
table-standing unit
includes:
1. System main body
2. Cable management shroud
3. Large back metal fixtures
4. Large hinge caps
5. Main prop
6. Rubber Slip:
When the system is to be assembled as a 30
o
table-standing unit, the rubber slip has to be inserted to
the front opening of the laid-down main prop to make
the whole unit look complete and integrated.
