8-29 Periodic Maintenance and Adjustment
IMPORTANT
When the fuel line is disconnected for
maintenance or repair, close both ends of the
fuel line with a piece of clean cloth or paper
to prevent dust and dirt from entering.
Particular care must be taken not to allow
dust and dirt into the fuel pump entrance.
Even a small amount of dust or dirt cause
premature wear and the malfunction of the
fuel pump and injector components.
① fuel pump ② fuel line
③ Exit pipe
4. To remove the in-line fuel filter clamps
(b), slide the clamps (b) away from the
in-line fuel filter (a). Twist and pull the
fuel lines off of the in-line fuel filter (a).
5. Check the in-line filter (a) for debris
and/or water contamination. Replace as
necessary.
