AXIS 207 - Technical Specifications
Technical Specifications
Item Specification
Model AXIS 207 Network Camera
Lens • 4.0mm, fixed iris
• F2.0
Image sensor 1/4” Micron progressive scan RGB CMOS
Angle of view Horizontal viewing angle: 55°
Light sensitivity 1-10000 Lux, F2.0
Video compression • Motion-JPEG. Snapshot JPEG images available.
• Ten user-controlled compression levels.
• MPEG-4 Part 2.
Resolutions • 640x480
• 480x360
• 352x288
• 320x240
• 240x180
• 176x144
• 160x120.
Frame rate Up to 30 fps in all resolutions
Image settings • Configurable compression level
• Rotation: 0
o
, 180
o
• Configurable color level, brightness, sharpness, white balance
• Overlay capabilities: time, date and text
Shutter time • 1/2 - 1/10000 sec
Security Multi-user password protection.
Users • 10 simultaneous users
• Unlimited number of users using multicast (MPEG-4)
Connectors • Ethernet 10BaseT/100BaseTX, RJ-45
• Mini DC power jack
• Terminal block for 1 alarm input and 1 output
Processors & memory • ARTPEC-A CPU and compression chip
• 32 MB SDRAM
• 4 MB Flash memory
• Linux kernel
Power 5.1V DC, max 2.5W
Operating Conditions (for
indoor use only)
• Temperature: +5
o
C to +50
o
C (41
o
F to 122
o
F)
• Humidity: 20-80% RHG
Installation, management and
maintenance
• Installation tool on CD and Web-based configuration
• Configuration backup and restore
• AXIS Camera Explorer for recording
• Firmware upgrades over HTTP or FTP, firmware available at www.axis.com
Video access from browser • Camera live view
• Customizable HTML pages
