Axis 209MFD - Technical Specifications

40
AXIS 209MFD/MFD-R/MFD-R M12
Technical Specifications
Item Specification
Models AXIS 209MFD: Megapixel
AXIS 209MFD-R: Megapixel, with a rugged and IP67-rated RJ-45 connector
AXIS 209MFD-R M12: Megapixel, with a rugged and IP67-rated M12 connector
Image sensor 1/3” Micron Progressive Scan RG B 1.3 Megapixel CMOS
Lens • 3.6mm, F1.8, fixed iris
• Focus range:
0.5m to infinity
Angle of view • 74° horizontal
Camera angle
adjustment
• Tilt: 0-90°
• Pan: ±10°
• Rot
ation: ±10°
Illumination 3 - 10000 lux, F1.8
Video compression • Motion JPEG
• MPEG-4
Part 2 (ISO/IEC 14496-2) with motion estimation
• Profiles: SP and ASP
Resolutions 24 resolutions from 1280x1024 to 160x90 via API, 19 selections via configuration page
Frame rate • Up to 12 fps in 1280x1024 (Motion JPEG)
• Up to
8 fps in 1280x1024 (MPEG-4)
Video streaming • Simultaneous Motion JPEG and MPEG-4
• Con
trollable frame rate and bandwidth
• Constant and variable bit rate (MPEG-4)
Image settings • Compression levels: 100
• Rotation: 0º, 180º
• Mirroring
• Configurable color level, brightness, sharpness, white balance, exposure control, backlight compensation
• Overlay capabilities: time, date, text, image or privacy mask
Pan/tilt/zoom • Digital PTZ
• 20 preset positions,
guard tour, sequence mode
• Supports Windows compatible joysticks
Shutter time 1/15000 s to 1/4 s
Security • Multiple user access levels with password protection
• IP address filtering
• HTTPS encryption
• Digest authentication
Users • 20 simultaneous users
• Unlimited
number of users using multicast (MPEG-4)
Alarm and event
managem
ent
• Image upload over FTP, email and HTTP
• Notification over TCP, email and HTTP
• 20 MB of pre- and post alarm buffer (300 images or more, in full 1280x1024 resolution)
(AXIS 209MFD)
• Events triggered by video motion detection, or according to a schedule
(AXIS 209MFD-R/AXIS 209MFD-R M12)
• Events triggered by video motion detection, tampering alarm, or accordi
ng to a schedule
Connectors • (AXIS 209MFD) Female RJ-45 for Ethernet 1
0BaseT/100BaseTX
• (AXIS 209MFD-R) Rugged, female RJ-45 connector.
• (AXIS 209MFD-R M12) Rugged, male M12 D-code connector.
Casing • Polycarbonate base and polycarbonate transparent cover
• Tamper-proof mounting
(AXIS 209MFD-R/AXIS 209MFD-R M12)
• IP66
Processors, memory,
clock
• CPU, video processing and compression: ARTPEC-A
• RAM: 64MB
• Flash memory: 8 MB
Power Power over Ethernet IEEE 802.3af, Class 1
