Axis 211 User Manual

A3090-1.1 en 3
Network Camera Devices
Contents Page
Safety Information 5
1 Getting Started 9
1.1 Overview 9
1.1.1 Equipment 9
1.2 Step 1: Set Up the Network Camera 9
1.2.1 Reset the Camera to Factory Default 9
1.2.2 Configure the Camera 10
1.3 Step 2: Configure and Run a Test 11
1.3.1 Add a Camera Message Channel 11
1.4 Step 3: View the Camera Data 12
2 Troubleshooting 15
2.1 Troubleshooting During Configuration 15
2.2 Troubleshooting After Configuration 15
2.3 Configured Axis M7001 Does Not Show Video 15

Axis 211 Specifications

General

Camera Type	Network camera
Connectivity	Wired
Image Sensor	1/4" progressive scan CMOS
Resolution	640x480 (VGA)
Operating Conditions	0 °C to 50 °C (32 °F to 122 °F)
Storage Temperature	-20 °C to 60 °C (-4 °F to 140 °F)
Lens	4.0 mm
Viewing Angle	54°
Minimum Illumination	1.5 lux
Video Compression	Motion JPEG
Frame Rate	30 fps
Network Protocols	HTTP, SMTP, FTP, DNS, DDNS, DHCP, ARP, ICMP
Ethernet	10/100
