Axis A1001 Datasheet

TechnicalSpecications-AXISEntryManager
Models
AXISA1001NetworkDoorControllerwithbuilt-inweb-based
software
Doorcontroller
Readers
Upto2readerspercontroller(Wiegand,RS485(OSDP))with
supportedcardformats
Controllers
1–33
a
Credentials
Upto400
Eventhistory
30000FirstIn,FirstOut(FIFO)percontroller
DigitalI/O
I/OinterfaceReaderI/O:DCoutput:2x12VDCoutputmax300mA;2x4
congurableinputs/outputs,(Digitalinput:0tomax40VDC,
Digitaloutput:0tomax40VDC,Opendrain,max100mA)
Readerdata:RS485fullduplex,RS485halfduplex,Wiegand
Auxiliary:1x3.3VDCoutput,max100mA
2xcongurableinputs/output(Digitalinput:0tomax40VDC,
Digitaloutput:0tomax40VDC,Opendrain,max100mA)
Doorconnectors:2x2inputfordoormonitorsandREX(Digital
input:0tomax40VDC)
I/Ofunctionality
Pre-conguredforreadersanddoormonitors,Inputtrigger,
Outputtoggle/pulse
Network
SecurityPasswordprotection,IPaddressltering,HTTPS
b
encryption,
IEEE802.1Xnetworkaccesscontrol,Digestauthentication,User
accesslog
Supported
protocols
IPv4,HTTP,HTTPS
b
,SSL/TLS
b
,QoSlayer3DiffServ,FTP,SMTP,
Bonjour,UPnP
TM
,SNMPv1/v2c/v3(MIB-II),DNS,DynDNS,NTP,
RTSP,RTP,TCP,UDP,IGMP,RTCP,ICMP,DHCP,ARP,SOCKS
Events&alarms
Tamperdetection
Removalofunitcover/tamperfront
Removalofunitfromwall/tamperback,Readertamper
Eventlog
Congurablebytimeandtopic,Alarmacknowledgement
Eventactions
Noticationviaemail,HTTPandTCP,Externaloutputport
StatusLED
Eventtriggers
Tamperdetection,Powerloss,Networklost,Conguration,Door,
Eventlogger,Hardware,Inputsignal,Schedule,System,Time
Systemfeatures
AccessschedulesUnlimited
Installation&
Conguration
Congurationwizard,Congurationverication,Color-coded
connectors,I/Oassignmentprint-out,Automaticcontroller
discovery,Instantfeedbackofmissingcongurationdata
AdministrationDrag-and-dropoperationwithexibleassignmentofdoors
andusergroups,Retrievecredentialsfromreader,Manual
access/lock/unlock,Importofusers
General
Casing
Plastic
SoftwareCongurationandbasicaccesscontrolmanagementthrough
InternetExplorer,Firefox,Chrome,orSafari
Memory
256MBRAM,4GbitFlash
Power
Powerin:10–30VDC,max26Wor
PoweroverEthernetIEEE802.3af/802.3atType1Class3
Powerout&relay:1x12VDC,max500mA
1xsolidstaterelay30VDC,max700mA
Poweroutlock:2x12VDC,max500mA
a
Connectors
RJ4510BASE-T/100BASE-TXTerminalblocks:DCpower,
10Inputs/Outputs,RS485/Wiegand,Relay,Cablesizefor
connectors:CSA:AWG28–16,CUL/UL:AWG30–14
Operating
conditions
0°Cto50°C(32°Fto122°F)
Humidity20–85%RH(non-condensing)
Approvals
EN55022ClassB,EN50130-4,EN61000-3-2,
EN61000-3-3,EN55024,EN61000-6-1,EN61000-6-2,
FCCPart15SubpartBClassB,ICES-003ClassB,
C-tickAS/NZSCISPR22ClassB,VCCIClassB,IEC/EN/UL60950-1,
UL294,UL2043,EN50581
Dimensions
45.5x180x180mm(1.8x7.1x7.1in)
Weight
500g(1.1lb)
Included
accessories
Connectorkit,Cableties,InstallationGuide
Optional
accessories
AXIST8120Midspan15W,AXIST8128PoESplitter24V(requires
30Wmidspan),AXIST8129PoEExtender
Mainsadaptor24VDC,AXIST98A15-VESurveillanceCabinet
Warranty
Axis3-yearwarrantyandAXISExtendedWarrantyoption,see
www.axis.com/warranty
a.Thenumberofcontrollersinthesystemispowerconsumptiondependent;maxload
percontrollerforreadersandotherequipmentis7.5WwithPoEand14Wwith
10–30VDC
b.ThisproductincludessoftwaredevelopedbytheOpenSSLProjectforuseinthe
OpenSSLToolkit(http://www.openssl.org/),andcryptographicsoftwarewrittenby
EricYoung(eay@cryptsoft.com).
Moreinformationisavailableatwww.axis.com
Dimensionsandconnectors
I/Ointerface
1.
Readerdata
2.
ReaderI/O
3.
Door
4.
Auxiliary
Externalpowerinputs
5.
Power(10–30VDC)
6.
Network(PoE)
Poweroutputs
7.
Powerlock
8.
Power&relay
www.axis.com
©2013AxisCommunicationsAB.AXISCOMMUNICATIONS,AXIS,ETRAX,ARTPECandVAPIXareregisteredtrademarksor
trademarkapplicationsofAxisABinvariousjurisdictions.Allothercompanynamesandproductsaretrademarksorregistered
trademarksoftheirrespectivecompanies.Wereservetherighttointroducemodicationswithoutnotice.
51232/EN/M1.7/112013

Axis A1001 Specifications

General

Interface	RS-485
Built-in UPS	-
Maximum number of doors	2 door(s)
DC voltage range	10 - 30 V
Power consumption (typical)	26 W

Weight and Dimensions

Depth	45.3 mm
Width	180 mm
Weight	500 g
