Specifications
Normaluse(notevaluatedbyUL)-40°Cto55°C(-40°Fto131°F)
Humidity20–85%RH(non-condensing)
UL294
0°Cto55°C(32°Fto131°F),maximumhumidity85%.
IntendedforuseinULlistedenclosurewithtamperswitch.
•Wiringrequirements
-ULlistedorR/CAWMwiresthathaveaconductorgaugerangeofAWG22–14shallbeused.
-Theminimumconductorgaugeforconnectionbetweenthepowersourcingequipment(PSE)orpowerinjector
andthepowereddevice(PD)is26AWG.
-MinimumPoEcategory5e,shieldedcable,requiredforPoE.
-ThisproductisnotintendedforoutsidewiringascoveredbyArticle800intheNationalElectricalCode,NFPA70.
•Connectors
-PowerConnector–ForULsecurityapplications,theproductshallbepoweredbyaUL294orUL603listed
Class2low-voltagepowerSELVandlimitedpowersupplywithappropriateratings.
-Externalpowertorelays-IftherelaysareconnectedtoanexternalpowersourcethismustbeUL294listed
Class2low-voltagepowerSELVandlimitedpowersupply.
-NetworkConnector–StandardEthernetwiring.EvaluatedbyULwhenpoweredfromAXIST8133Midspan30
W1-portinPoEModeB(alternativeA).
-BatteryinputisforconnectiontoalistedUPSandhasnotbeenevaluatedbyULtoUL294.
-SupervisedinputswerenotevaluatedbyULforburglaruse.
•Systemconsiderations
-MonitoringsoftwarewasnotevaluatedbyUL,andisforsupplementaluse.
•Maintenanceinstructions
-FormaintenanceinstructionsandforinformationabouthowtoconguretheAxisproduct,seetheUserManual.
•Furtherinformation
-CardformatsveriedbyUL:ISOCardsMifare1K,32bits.
•Power
-Powerin:10.5–28VDC,max36W,max2.4Aat10.5V,max0.9Aat28V.
PoweroverEthernet(PoE)IEEE802.3atType2Class4,max340mA.12Vbatteryas
backup.
-Relay:2xrelayNO/NC,max2ADC
-Poweroutlock:2x12/24VDC,
WithPoE+:at12V,11W,at24V,10W
WithDCin:at12V,22.5W,at24V,18W
-Poweroutreader:12VDC,max6W
-AuxiliaryDCoutput:1x12VDCoutput,max200mA
-Totalpowerbudgetforperipheraldevices(locks,readersetc.):2100mAat12VifpoweredbyDC,1300mAat
12VifpoweredbyPoEClass4
•I/Ointerface–I/Ofunctionality
22
