AXISA4011-EReader
HardwareOverview
1
3
2
Front(left)
1
Frontplate
2
ReaderfeedbackLED
indicators
3
Frontplatescrew(T20)
4
5
6
Back(right)
4
Backplate
5
Tamperingalarmswitch
6
Power&Dataconnector
ReaderFeedback
Thetablebelowshowsthefeedbacksignalsthatarepreconguredinthereaderwhenconnected
toanAxisnetworkdoorcontroller.
Event/state
LEDindicatorBeeperpattern
Doorlocked
Steadyred
Silent
Doorunlocked
Steadygreen
Silent
PINrequired
Steadyred/Steadyamber
Twoshortbeeps
EnteringPIN
Steadyred/Steadyamber
Silent
Accessgranted
Steadygreen
Oneshortbeep
6
