CONTROL FUNCTIONS
1. POWER ON/OFF ( )
2. UNCTION SELECT BUTTON:BASS/TREBLE/BALANCE/FADER / AUDIO DSP/ESP/BEEP/
SEEK/VOL LAST (SEL)
3. VOL UP/VOL DOWN FOR BASS/TREBLE/BALANCE/FADER
4. PRESET STATIONS (1,2,3,4,5,6)
5. STEREO/MONO BUTTON (ST)
6. LOUDNESS BUTTON (LD)
7. LOCAL/DISTANT SELECT (LOC)
8. DISPLAY BUTTON (DISP)
9. MODE BUTTON (MODE)
10. BAND / SUBWOOFER BUTTON (BD/SUB)
11. AUTOMATIC OR MANUAL TUNING (FREQ UP OR
FREQ DOWN ) / CD TRACK/SEARCH BUTTON
12. AUTO SEEK SEARCH TUNING (A/PS)
13. ‘SCAN’ AUTOMATIC TUNING CONTROL (SCN)
14. MUTE BUTTON ( )
15. LCD DISPLAY
16. OPEN PANEL BUTTON ( )
17. CD SLOT
18. CD EJECT BUTTON ( )
19. PAUSE BUTTON
20. INTRO BUTTON (Preview all Tracks)
21. REPEAT BUTTON ‘RPT’
22. RANDOM BUTTON ‘RDM’
23, 24. 10 TRACK DOWN/UP SELECT: (In case of MP3/WMA les)
25. AUX IN
LOCATIONS OF PARTS
