AXISD3110ConnectivityHub

Speciﬁcations

Amber/RedFlashesamber/redifnetworkconnectionisunavailableorlost.

RedFlashesredforrmwareupgradefailure.

SDcardslot

ForSDcardrecommendations,seeaxis.com.

microSD,microSDHC,andmicroSDXCLogosaretrademarksofSD-3CLLC.microSD,microSDHC,microSDXCare

trademarksorregisteredtrademarksofSD-3C,LLCintheUnitedStates,othercountriesorboth.

Buttons

Controlbutton

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.SeeResettofactorydefaultsettingsonpage37.

•Connectingtoaone-clickcloudconnection(O3C)serviceovertheinternet.Toconnect,pressandholdthebutton

forabout3secondsuntilthestatusLEDashesgreen.

Connectors

Networkconnector

RJ45Ethernetconnector.

Input:RJ45EthernetconnectorwithPoweroverEthernet(PoE).

Output:RJ45EthernetconnectorwithPoweroverEthernet(PoE).

Audioconnector

•Audioin–3.5mminputforastereomicrophone,oraline-instereosignal.

•Audioout–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoranactive

speakerwithabuilt-inamplier.Astereoconnectormustbeusedforaudioout.

Audiooutput

1Tip2Ring

3Sleeve

Channel1,unbalancedline,monoChannel1,unbalancedline,monoGround

I/Oconnector

UsetheI/Oconnectorwithexternaldevicesincombinationwith,forexample,motiondetection,eventtriggering,andalarm

notications.Inadditiontothe0VDCreferencepointandpower(DCoutput),theI/Oconnectorprovidestheinterfaceto:

Digitalinput-Forconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,forexamplePIRsensors,door/window

contacts,andglassbreakdetectors.
