AXISF41MainUnit
TechnicalSpecifications
PowerConnector
2-pinterminalblockforDCpowerinput.UseaSafetyExtraLowVoltage(SELV)compliant
limitedpowersource(LPS)witheitheraratedoutputpowerlimitedto≤100Woraratedoutput
currentlimitedto≤5A.
AudioConnector
3.5mmaudioconnectors
(stereo)
1Tip2Ring
3Sleeve
AudioInput
Microphone/Linein
Balanced:‘Hot’signalMicrophone/Linein
Unbalanced:Microphone/Linein
Balanced:‘Cold’signalMicrophone/Line
in
Unbalanced:Unused
Ground
AudioOutput
Lineout,mono(stereoconnector
compatible)
Lineout,mono(stereoconnector
compatible)
Ground
Theinternalmicrophoneisusedbydefault;theexternalmicrophoneisusedwhenconnected.Itispossibletodisabletheinternal
microphonebyconnectingaplugtothemicinput.
ConnectionDiagrams
I/OConnector
1
2
3
A
B
D
S
G
1
0VDC(-)
2
DCoutput12V,max50mA
