Technical Specications – AXIS M30 Network Camera Series
Camera
Models AXIS M3004-V: 1 MP / HDTV 720p, vandal and dust resistant
AXIS M3005-V: 2 MP / HDTV 1080p, vandal and dust resistant
AXIS M3006-V: 3 MP / HDTV 1080p, vandal and dust resistant
AXIS M3007-P: 5 MP, 360°/180°, discreet smoke-detector look
AXIS M3007-PV: 5 MP, 360°/180°, vandal and dust resistant
Note: AXIS M3011 and AXIS M3014 are handled separately from the
new AXIS M30 Series
Image sensor AXIS M3004-V: 1/4” progressive scan RGB CMOS
AXIS M3005-V: 1/2.7” progressive scan RGB CMOS
AXIS M3006-V: 1/3.6” (effective) progressive scan RGB CMOS
AXIS M3007-P/-PV: 1/3.2” progressive scan RGB CMOS
Lens M12 mount, F2.8, fixed iris, megapixel resolution
AXIS M3004-V: 2.8 mm, 80° horizontal angle of view
AXIS M3005-V: 2.8 mm, 118° horizontal angle of view
AXIS M3006-V: 1.6 mm, 134° horizontal angle of view
AXIS M3007-P/-PV: 1.3 mm, 187° horizontal angle of view
Light sensitivity AXIS M3004-V/M3005-V: 1.5 - 100000 lux, F2.8
AXIS M3006-V/M3007-P/M3007-PV: 0.6 - 200000 lux, F2.8
Shutter time AXIS M3004-V/M3005-V: 1/8000 s to 1/6 s
AXIS M3006-V: 1/30500 s to 2 s
AXIS M3007-P/M3007-PV: 1/24000 s to 2 s
Camera angle
adjustment
AXIS M3004-V/M3005-V: Pan ±175°, tilt ±45°, rotation ±175°
AXIS M3006-V: Pan ±180°, tilt 0-45°, rotation ±178°
AXIS M3007-P/-PV: Rotation ±180°
Video
Video
compression
H.264 Main Profile (MPEG-4 Part 10/AVC), Motion JPEG
AXIS M3006-V/M3007-P/M3007-PV: Also H.264 Baseline
Profile
Resolutions AXIS M3004-V: 1280x800 (1 MP) to 320x240
AXIS M3005-V: 1920x1080 (HDTV 1080p) to 320x240
AXIS M3006-V: 2048x1536 (3 MP) to 160x90
AXIS M3007-P/-PV: 2592x1944 (5 MP) to 160x90
Frame rate
H.264/Motion JPEG
AXIS M3004-V/M3005-V: 25/30 fps with power line frequency
50/60 Hz
AXIS M3006-V: 3 MP capture mode: 16/20 fps with power line
frequency 50/60 Hz
HDTV 1080p (1920x1080) and 2 MP 4:3 (1600x1200) capture
modes: 25/30 fps with power line frequency 50/60 Hz
AXIS M3007-P/-PV: 12 fps in 360° overview and panoramic
views
Video streaming Multiple, individually configurable streams in H.264 and
Motion JPEG
Controllable frame rate and bandwidth
VBR/CBR H.264
Multi-view
streaming
AXIS M3006-V: Up to 8 individually cropped out view areas.
When streaming 4 view areas and 1 overview in VGA resolution,
the frame rate is 16/20 fps per stream with power line
frequency 50/60 Hz (3 MP capture mode)
AXIS M3007-P/-PV: 360° overview, panorama, double
panorama, quad view. Up to 4 individually cropped out and
dewarped view areas. When streaming 4 dewarped view areas
and one 360° overview in VGA resolution, the frame rate is 10
fps per stream
Pan/Tilt/Zoom AXIS M3004-V/M3005-V: Digital PTZ
AXIS M3006-V: Digital PTZ, preset positions, guard tour
AXIS M3007-P/-PV: Digital PTZ with dewarping, preset
positions, guard tour
Image settings Compression, color, brightness, sharpness, contrast, white
balance, exposure control, backlight compensation, wide
dynamic range - dynamic contrast, text and image overlay,
privacy mask, mirroring of images
AXIS M3006-V/M3007-P/M3007-PV: Exposure zones, fine-
tuning of low light behavior
AXIS M3004-V/M3005-V/M3006-V: Rotation: 0°, 90°, 180°,
270°, including Corridor Format
AXIS M3007-P/-PV: Rotation: 0°, 180°
Network
Security Password protection, IP address filtering, HTTPS* encryption,
IEEE 802.1X network access control, digest authentication, user
access log
Supported
protocols
IPv4/v6, HTTP, HTTPS*, SSL/TLS*, QoS Layer 3 DiffServ, FTP,
CIFS/SMB, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS,
DynDNS, NT P, R TSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP,
SOCKS
System integration
Application
Programming
Interface
Open API for software integration, including VAPIX® and
AXIS Camera Application Platform from Axis Communications,
available at www.axis.com
AXIS Video Hosting System (AVHS) with One-Click Camera
Connection
AXIS M3004-V/M3005-V/M3006-V: ONVIF, specification
available at www.onvif.org
Intelligent video Video motion detection, active tampering alarm
AXIS Camera Application Platform enabling installation of
additional applications
(In AXIS M3007-P/-PV, additionally installed applications can be
used in the 360° overview mode only)
Event triggers Intelligent video, edge storage events
Event actions File upload: FTP, HTTP, network share and email; notification:
email, HTTP and TCP; video recording to edge storage; pre- and
post-alarm video buffering
AXIS M3006-V/M3007-P/M3007-PV: Go to PTZ preset, guard
tour
Data streaming Event data
Built-in
installation aid
Pixel counter
General
Casing Casing color: white NCS S 1002-B; encapsulated electronics
AXIS M3004-V/M3005-V: IP42 water- and dust-resistant,
IK08 impact-resistant, polycarbonate/ABS casing
AXIS M3006-V/M3007-PV: IP42 water- and dust-resistant,
IK08 impact-resistant, aluminum and polycarbonate/ABS casing
AXIS M3007-P: Discreet, smoke-detector like design with
uncovered lens, aluminum and polycarbonate/ABS casing
Memory AXIS M3004-V/M3005-V: 256 MB RAM, 128 MB Flash
AXIS M3006-V/M3007-P/M3007-PV: 512 MB RAM, 128 MB
Flash
Power Power over Ethernet IEEE 802.3af
AXIS M3004-V: Class 1, max. 2.2 W
AXIS M3005-V: Class 1, max. 2.7 W
AXIS M3006-V: Class 2, max. 4.5 W
AXIS M3007-P/-PV: Class 2, max. 4.6 W
Connectors Male RJ-45 10BASE-T/100BASE-TX PoE on a 2 m (6.6 ft.)
network cable
Edge storage MicroSD/microSDHC/microSDXC slot supporting memory
card up to 64 GB (card not included); support for recording to
network share (network-attached storage or file server)
Operating
conditions
Humidity 15 - 85% RH (non-condensing)
AXIS M3004-V/M3006-V/M3007-P/M3007-PV: 0 ºC to 45 ºC
(32 ºF to 113 ºF)
AXIS M3005-V: 0 ºC to 40 ºC (32 ºF to 104 ºF)
Approvals EN 55022 Class B, EN 61000-6-1, EN 61000-6-2, EN 55024,
FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B,
C-tick AS/NZS CISPR 22 KCC Class B, IEC/EN/UL 69050-1
All models except AXIS M3007-P: IEC 60529 IP42, IEC 62262
Class IK08
Weight AXIS M3004-V/M3005-V: 200 g (0.44 lb.)
AXIS M3006-V: 640 g (1.4 lb.); AXIS M3007-P: 570 g (1.3 lb.)
AXIS M3007-PV: 610 g (1.4 lb.)
Included
accessories
Drill hole template, Installation Guide, Installation and
Management Software CD, Windows decoder 1-user license,
Torx L-key
* This product includes software developed by the OpenSSL Project for use
in the OpenSSL Toolkit. (www.openssl.org)
More information is available at www.axis.com
©2013 Axis Communications AB. AXIS COMMUNICATIONS, AXIS, ETRAX, ARTPEC and VAPIX are registered trademarks or trademark applications of Axis AB
in various jurisdictions. All other company names and products are trademarks or registered trademarks of their respective companies. We reserve the right
to introduce modications without notice.
