Technical Specications – AXIS M30 Network Camera Series
www.axis.com
©2009 Axis Communications AB. AXIS COMMUNICATIONS, AXIS, ETRAX, ARTPEC and VAPIX are registered trademarks or trademark applications of Axis AB
in various jurisdictions. All other company names and products are trademarks or registered trademarks of their respective companies. We reserve the right
to introduce modications without notice.
35327/EN/R2/0905
More information is available at www.axis.com
Dimensions Optional accessories
For information on AXIS Camera Station and
video management software from
Axis’ Application Development Partners, see
www.axis.com/products/video/software/
Camera
Image sensor AXIS M3011: 1/4 ” Progressive scan RGB CMOS VGA
AXIS M3014: 1/4” Progressive scan RGB CMOS 1 Megapixel
Lens AXIS M3011: 3.0 mm, F2.0, fixed iris
Horizontal angle of view: 66°
AXIS M3014: 2.9 mm, F2.0, fixed iris
Horizontal angle of view: 80°
Minimum
illumination
1 lux, F2.0
Shutter time AXIS M3011: 1/5000 s to 1/4 s
AXIS M3014: 1/25000 s to 1/6 s
Pan/Tilt/Zoom AXIS M3014: Digital PTZ, preset positions, guard tour
Video
Video
compression
AXIS M3011: H.264 (MPEG-4 Part 10/AVC), Motion JPEG,
MPEG-4 Part 2 (ISO/IEC 14496-2)
AXIS M3014: H.264 (MPEG-4 Part 10/AVC), Motion JPEG
Resolutions AXIS M3011: 640x480 to 160x120
AXIS M3014: 1280x800 to 160x90
Frame rate
H.264
30 fps in all resolutions
Frame rate
Motion JPEG
30 fps in all resolutions
Frame rate
MPEG-4 Part 2
AXIS M3011: 30 fps in all resolutions
Video streaming Controllable frame rate and bandwidth
AXIS M3011: Multi-stream H.264, Motion JPEG and
MPEG-4 Part 2
H.264/MPEG-4 Part 2: 1 stream in full frame rate and
resolution, Motion JPEG: 2 individually configured streams
in full frame rate and resolution, more streams in either
compression if identical or limited in frame rate/resolution
VBR/CBR H.264 & MPEG-4 Part 2
AXIS M3014: Multi-stream H.264 and Motion JPEG
H.264/Motion JPEG: 1 stream in full frame rate and resolution in
either compression, more streams if identical or limited in frame
rate/resolution
VBR/CBR H.264
Image settings Compression, color, brightness, sharpness, contrast, white
balance, exposure control, exposure zones, backlight
compensation, fine tuning of behavior at low light, rotation
Text and image overlay
Privacy mask
AXIS M3014: Mirroring of images
Network
Security Password protection, IP address filtering, HTTPS* encryption,
digest authentication, user access log
Supported
protocols
IPv4/v6, HTTP, HTTPS*, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour,
UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP,
TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
System integration
Application
Programming
Interface
Open API for software integration, including VAPIX® from
Axis Communications available at www.axis.com
Intelligent video Video motion detection, active tampering alarm
Alarm triggers Intelligent video
Alarm events File upload via FTP, HTTP and email
Notification via email, HTTP and TCP
Video buffer AXIS M3011: 16 MB pre- and post alarm
AXIS M3014: 40 MB pre- and post alarm
General
Casing Metal camera module holder, plastic camera module casing,
plastic transparent cover and white cover ring
Processor and
memory
AXIS M3011: ARTPEC-B, 64 MB RAM, 32 MB Flash
AXIS M3014: ARTPEC-3, 128 MB RAM, 128 MB Flash
Power Power over Ethernet IEEE 802.3af Class 1
Connectors RJ-45 10BASE-T/100BASE-TX PoE
Operating
conditions
Humidity 20 - 80% RH (non-condensing)
AXIS M3011: 0 – 50
º
C (32 – 122
º
F)
AXIS M3014: 0 – 45 ºC (32 – 113 ºF)
Approvals EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024,
FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B,
C-tick AS/NZS CISPR 22, MIC Class B, EN 60950-1
AXIS M3014: KCC class B
Weight 260 g (0.6 lb.)
(midspan not included)
Included
accessories
AXIS PoE Midspan 1-port, Installation Guide, CD with
installation tools, recording software and User’s Manual,
Windows decoder 1-user license
