Hardware overview
Lens holder
180° mark
Optic holder
LED indicators
Lens tool
Black rubber side (for focus adjustment)
Netzwerkkabel
cable (0.5m/1.6ft.)
Optic mount
Use screws here to mount camera
Top cover tool
(top of image)
Control button
Transparent side
(for image adjustment)
Lens tool
(AXIS M3114-R M12 2MM)
Lens tool for adjusting image
Lens tool for adjusting focus
