AXISM5075-GPTZCamera

Conﬁgureyourdevice

Basicsettings

Setthecapturemode

1.GotoVideo>Installation>Capturemode.

2.ClickChange.

3.SelectacapturemodeandclickSaveandrestart.

SeealsoCapturemodesonpage56.

Setthepowerlinefrequency

1.GotoVideo>Installation>Powerlinefrequency.

2.ClickChange.

3.SelectapowerlinefrequencyandclickSaveandrestart.

Settheorientation

1.GotoVideo>Installation>Rotate.

2.Select0or180degrees.

Adjusttheimage

Thissectionincludesinstructionsaboutconguringyourdevice.Ifyouwanttolearnmoreabouthowcertainfeatureswork,go

toLearnmoreonpage56.

Levelthecamera

Toadjusttheviewinrelationtoareferenceareaoranobject,usethelevelgridincombinationwithamechanicaladjustment

ofthecamera.

1.GotoVideo>Image>andclick

2.Click

toshowthelevelgrid.

3.Adjustthecameramechanicallyuntilthepositionofthereferenceareaortheobjectisalignedwiththelevelgrid.

Adjustthefocus

Thisproductcanhavefourfocusmodes:

•Auto:Thecameraautomaticallyadjustsfocusbasedontheentireimage.

•Area:Thecameraautomaticallyadjustsfocusbasedonaselectedareaoftheimage.

•Manual:Thefocusissetmanuallyataxeddistance.

•Spot:Thefocusissettoaxedareainthecenteroftheimage.

Spotfocus
