AXISM5525-EPTZNetworkCamera

Howtoconnectamicrophonetothecamera

Thisexampleexplainshowtoconnectamicrophonetothecamerausinganaudioextensioncable.

Requiredhardware

•AXIST8351Microphone3.5mm

•AXISAudioExtensionCableA,5m(16ft)

Note

•Toavoidnoise,don'trunthecableclosetoorinparallelwithothercables.

•Toavoidnoise,cutthecableasshortaspossible.

•TomaintainIP66rating,makesureyoukeepthejackinsidethehousing.

Connectthecables

1.Keepthe3.5mmjackandcuttheaudioextensioncable.

2.Striptheoutercableinsulation.

3.Striptheinnerwireinsulation.

4.Twisttheaudiowires(withinsulation)together.

5.Twistthegroundingwires(withoutinsulation)together.

6.ConnecttheaudiowirestotheAUDIOINpinonthecamera.SeeProductoverviewonpage3.

7.ConnectthegroundingwirestotheGNDAUDIOINpinonthecamera.

8.Connectthemicrophonetothejackoftheaudioextensioncable.

9.Turnonaudioandadjustotheraudiosettingsinthecamera'swebpage.
