AXIS P1346 Network Camera
Detectors
Set Up Motion Detection
To set up a motion detection Include Window , follow these instructions:
1. Go to Detectors > Motion Detection.
2. Select a desired resolution for viewing while se tting up Motion Detecti o n from the View in list.
3. Select the Configure Included Windows option and click New. Select the new w indow in the list of windows and enter
adescriptivename.
4. Adjust the size (drag the bottom right-hand corner) and the position (click on the text at the top and drag to the desired
position) o f the active w indow (window with red frame).
5. Adjust the Object Size, History and Sensitivity profile sliders (see Motion detection parameters for deta ils). Any detected
motion within an active window is indicated by red peaks in the Activity window.
6. Click Save.
To exclude parts of the include window, select the Configure Excluded Windows and position the exclude window within the
include window.
To delete an include or exclude window, select
the window in the list of windows and cl ick Del.
Motion detection parameters
The parameters controlling motion detection are described in the table below:
Parameter
Object Size
History
Sensitivity
Description
Object size relative to window
size.
Object memory length.
Difference in luminance
between background and
object.
High level (100%)
Only very large objects trigger
motion detection.
An object that appears in
the window triggers motion
detection f
or a long time
before it is considered as
non-moving.
Ordinary colored objects on
ordinary backgrounds trigger
motion detection.
Medi
um level (50%)
A large difference in luminance
is required to trigger motion
detection.
32
