Axis P13-E Series User Manual

AXIS P1346 Network Camera
Hardware overview
Green
Normal oper ation.
Power
Amber
Flashes green/amber during firmware upgrade.
Note
• The Status LED can be configured to be unlit during normal operation. To configure, go to Setup > System Options >Ports
& Devices >LED. See the online help for more information.
• The Status LED can be configured to flash while an event is active.
• The Status LED can be confi gured to flash for identifying the unit. This can be done under Setup > System Options >
Maintenance.
Status LED when using Focus Assistant
Status Color
Indication
Green
Focus Assistant is enabled
The lens is optimally adjusted
Amber The camera has been moved, or an object has been inserted in front of t he lens. Exit and
restart the Focus Assistant.
The lens is less optimally adjusted
Red The camera has been moved, or an object has been inserted in front of the lens. Exit and
restart the Focus Assistant.
The lens is poorly adjusted
Replacing the lens
It is possible to use optional lenses for the Axis product.
To replace the lens:
1. Disconnect the iris cable.
2. Unscrew the standard lens.
3. Attach and screw on the new lens.
Note
There is no need to restart the Axis product after changing the lens. However, the product must be restarted if you are
interchanging between a P-iris, DC-Iris or fixed/manual iris lens. In order to set the focus and po sition the lens, the Axis
product must be connected to the network.
To change the iris configuration:
1. Go to Setup > Video and Audio > Camera Settings. Iris configuration shows the current configured iris type.
2. Click Edit.
3. Select the installed iris l ens from the d rop-down list and click OK.
8
