AXISP13NetworkCameraSeries

Speciﬁcations

Buttons

Controlbutton

Thecontrolbuttonisusedfor:

•EnablingtheFocusAssistant.PressandveryquicklyreleasetheControlbutton.

•Resettingtheproducttofactorydefaultsettings.SeeResettofactorydefaultsettingsonpage16.

Connectors

Networkconnector

RJ45EthernetconnectorwithPoweroverEthernet(PoE).

Audioconnector

TheAxisproducthasthefollowingaudioconnectors:

•Audioin–3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelisusedfromastereosignal).

•Audioout–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoranactive

speakerwithabuilt-inamplier.Astereoconnectormustbeusedforaudioout.

3.5mmaudioconnectors(stereo)

1Tip2Ring

3Sleeve

AudioInput

Microphone/Linein

Ground

AudioOutput

Lineout(mono)

Ground

Illuminatorconnector

4-pinconnectorusedtoconnectAXISFixedBoxIlluminatorKitAtothecamera.

I/Oconnector

UsetheI/Oconnectorwithexternaldevicesincombinationwith,forexample,motiondetection,eventtriggering,andalarm

notications.Inadditiontothe0VDCreferencepointandpower(12VDCoutput),theI/Oconnectorprovidestheinterfaceto:

Digitalinput-Forconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,forexamplePIRsensors,door/window

contacts,andglassbreakdetectors.

Supervisedinput-Enablespossibilitytodetecttamperingonadigitalinput.

Digitaloutput-ForconnectingexternaldevicessuchasrelaysandLEDs.ConnecteddevicescanbeactivatedbytheVAPIX®

ApplicationProgrammingInterface,throughaneventorfromthedevice’swebinterface.
