Page 6 AXIS P1353/P1354 Installation Guide
Hardware overview
Internal microphone
Zoom puller
Focus puller
LED indicator
Network connector PoE
Audio out
Audio in
Iris connector
Power connector
RS485/422 connector
I/O terminal block
Control button
Network LED
Power LED
SD card slot (microSD)
Product number (P/N) & Serial number (S/N).
The serial number may be required during the
installation.
