AXISP1355NetworkCamera
SetUptheProduct
SetUptheProduct
TheAxisproductcanbeconguredbyuserswithadministratororoperatorrights.Toopentheproduct’sSetuppages,clickSetupin
thetopright-handcorneroftheLiveViewpage.
•Administratorshaveunrestrictedaccesstoallsettings.
•OperatorshaveaccesstoallsettingsexceptSystemOptions
Seealsotheonlinehelp
.
BasicSetup
BasicSetupprovidesshortcutstothesettingsthatshouldbemadebeforeusingtheAxisproduct:
1.Users.Seepage49.
2.TCP/IP.Seepage52.
3.Date&Time.Seepage51.
4.VideoStream.Seepage21.
5.Focus.Seepage28
6.AudioSettings.Seepage28.
TheBasicSetupmenucanbedisabledfromSystemOptions>Security>Users.
AdjustFocus
Toadjustthezoomandfocusfollowtheseinstructions:
Note
•SetthefocusaspreciseaspossiblewiththefocuspullerorFocusAssistantbeforestartingautomaticnetuning.Usingthe
focuspullernormallygivesthebestresult.
•Theirisshouldalwaysbeopenedtoitsmaximumwhilefocusing.Thisgivesthesmallestdepthofeldandthusthe
bestconditionsforcorrectfocusing.
1.Opentheproduct’shomepageandgotoSetup>BasicSetup>Focus.
2.UndertheBasictab,clickOpeniris.Ifthebuttonisinactivetheirisisalreadyopen.
3.Iffocushasbeensetbefore,clickResettoresetthebackfocus.
4.Loosenthezoomandfocuspullers(seeHardwareOverviewonpage7)onthelensbyturningthemcounter-clockwise.
Movethepullerstosetzoomandfocusandcheckthequalityoftheimageintheimagewindow.
Ifthecameraismountedsothatonecannotlookattheimageandmovethepullersatthesametime,usetheFocus
Assistantinstead.SeeFocusAssistantonpage20.
5.Loosenthezoompullerandthelockscrewforthefocusring(seeHardwareOverviewonpage7)onthelensbyturning
themcounter-clockwise.Movethezoompullerandthefocusringtosetzoomandfocusandcheckthequalityof
theimageintheimagewindow.
Ifthecameraismountedsothatyoucannotlookattheimageandmovethezoompullerandthefocusringatthesame
time,usetheFocusAssistantinstead.SeeFocusAssistantonpage20.
6.Re-tightenthezoomandfocuspullers.
