AXISP1355NetworkCamera

HardwareOverview

Controlbutton

I/Oterminalblock

Productnumber(P/N)andSerialnumber(S/N)

RS485/422connector

Powerconnector

Irisconnector

ConnectorsandButtons

Fortechnicalspecications,seepage67.

NetworkConnector

RJ45EthernetconnectorwithPoweroverEthernet(PoE).

NO NO

TICE TICE

TICE

Theproductshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnectingtheproducttothenetworkshall

beintendedfortheirspecicuse.Makesurethatthenetworkdevicesareinstalledinaccordancewiththemanufacturer’s

instructions.Forinformationaboutregulatoryrequirements,seeElectromagneticCompatibility(EMC)onpage2.

I/OConnector

Usewithexternaldevicesincombinationwith,forexample,tamperingalarms,motiondetection,eventtriggering,timelapserecording

andalarmnotications.Inadditiontothe0VDCreferencepointandpower(DCoutput),theI/Oconnectorprovidestheinterfaceto:

•Digitaloutput–ForconnectingexternaldevicessuchasrelaysandLEDs.Connecteddevicescanbeactivatedbythe

VAPIX®ApplicationProgrammingInterface,outputbuttonsontheLiveViewpageorbyanActionRule.Theoutputwill

showasactive(shownunderSystemOptions>Ports&Devices)ifthealarmdeviceisactivated.

•Digitalinput–Analarminputforconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,forexample:

PIRs,door/windowcontacts,glassbreakdetectors,etc.Whenasignalisreceivedthestatechangesandtheinputbecomes

active(shownunderSystemOptions>Ports&Devices).

PowerConnector

2-pinterminalblockforpowerinput.UseaSafetyExtraLowVoltage(SELV)compliantlimitedpowersource(LPS)witheitherarated

outputpowerlimitedto≤100Woraratedoutputcurrentlimitedto≤5A.

AudioConnector

TheAxisproducthasthefollowingaudioconnectors:

•Audioin(pink)–3.5mminputforamonomicrophone,oraline-inmonosignal.

•Audioout(green)–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoran

activespeakerwithabuilt-inamplier.Astereoconnectormustbeusedforaudioout.

Foraudioin,theleftchannelisusedfromastereosignal.

RS485/RS422Connector

TwoterminalblocksforRS485/RS422serialinterfaceusedtocontrolauxiliaryequipmentsuchasPTZdevices.
