AXISP1465-LE-3LicensePlateVerifierKit
Basicsetup
Capturedistance(x)Mountingheight(y)
7.0m(23ft)3.0m(9.8ft)
10.0m(33ft)4.0m(13ft)
15.0m(49ft)6.0m(19.5ft)
20.0m(65ft)10.0m(33ft)
•Thecamera’smountingangleshouldnotbelargerthan30°inanydirection.
Mountinganglefromtheside.
Mountinganglefromabove.
•Theimageofthelicenseplateshouldnottiltmorethan5°horizontally.Iftheimageistiltedmorethan5°,we
recommendedthatyouadjustthecamerasothatthelicenseplateisdisplayedhorizontallyinthelivestream.
