AXISP14-LEBulletCameraSeries
Configureyourdevice
SetthePIRdetectortoaninputport
1.GotoSystem>Accessories>I/Oports.
2.SetthedirectiontoInputforport1.
3.Givetheinputmoduleadescriptivename,forexample“PIRdetector”.
4.TotriggeraneventwheneverthePIRdetectorsensesmotion,setthenormalstatetoCircuitopen.
Settheswitchrelaytoanoutputport
1.SetthedirectiontoOutputforport2.
2.Givetheoutputmoduleadescriptivename,forexample“Gateswitch”.
3.Toopenthegatewheneveraneventistriggered,setthenormalstatetoCircuitclosed.
Createrules
ForthecameratoopenthegatewhenthePIRdetectorsensessomeonenearby,youneedtocreatearuleinthecamera:
1.GotoSystem>Eventsandaddarule.
2.Typeanamefortherule,forexample“Opengate”.
3.Inthelistofconditions,selectPIRdetector.
4.Inthelistofactions,selectToggleI/Oonce.
5.Inthelistofports,selectGateswitch.
6.SetstatetoActive.
7.Settheduration.
8.ClickSave.
9.Createanotherrulewiththename“Directthecameratothegate".
10.Selectthesameinputsignalasbefore,butasactionselectthepreviouslycreated“Gateentrance”presetposition.
11.ClickSave.
Recordvideowhenthecameradetectsloudnoises
ThisexampleexplainshowtosetupthecameratostartrecordingtotheSDcardvesecondsbeforeitdetectsloudnoiseand
tostoptwominutesafter.
Note
Thefollowinginstructionsrequirethatamicrophoneisconnectedtoaudio-in.
Turnonaudio:
1.Setupthestreamproletoincludeaudio,seeAddaudiotoyourrecordingonpage18.
Turnonaudiodetection:
1.GotoSystem>Detectors>Audiodetection.
2.Adjustthesoundlevelaccordingtoyourneeds.
Createarule:
16
