Technical Specications – AXIS Q1755 Network Camera
www.axis.com
©2008 Axis Communications AB. AXIS COMMUNICATIONS, AXIS, ETRAX, ARTPEC and VAPIX are registered trademarks or trademark applications of Axis AB
in various jurisdictions. All other company names and products are trademarks or registered trademarks of their respective companies. We reserve the right
to introduce modications without notice.
35818/EN/R1/0905
More information is available at www.axis.com
Dimensions Optional accessories
For information on AXIS Camera Station and
video management software from
Axis’ Application Development Partners, see
www.axis.com/products/video/software/
Various housings
[8,32”]211,4 mm
[6,04”]153,3 mm
[5,13”]130,4 mm
mm [3,35”]85
[6,78”]172,2 mm [0,54”]13,8 mm
[1,26”]64 mm
mm [0,2”] (x3)5
AXIS T90A Illuminators
Camera
Models
AXIS Q1755 50Hz
AXIS Q1755 60Hz
Image sensor
1/3’’ Progressive scan CMOS 2 Megapixel
Lens
f 5.1 - 51 mm, F1.8 - 2.1
Auto day/night IR filter, autofocus
Near focus limit 10mm (wide) or 800mm (tele)
Angle of view, horizontal: 5.4° - 50°
M37x0.75 mounting thread for optional lens adaptor
Minimum
illumination
Color: 2 lux at 30IRE, F1.8
B/W: 0.2 lux at 30IRE, F1.8
Shutter time
1/10000 s to 1/2 s
Zoom
10x optical and 12x digital, total 120x
Video
Video
compression
H.264
Motion JPEG
Resolutions
HDTV 1080i 1920x1080
HDTV 720p 1280x720
Standard NTSC/PAL for installation
Frame rate
H.264
30/25 fps in all resolutions
Frame rate
Motion JPEG
30/25 fps in all resolutions
Video streaming
Multi-stream H.264 and Motion JPEG: simultaneous, individually
configured streams in max. resolution at 25/30 fps
Controllable frame rate and bandwidth
VBR/CBR H.264
Image settings
Compression, brightness, sharpness, white balance, exposure control,
backlight compensation, rotation, mirroring of images
Text and image overlay
Privacy mask
Audio
Audio streaming
Two-way, half duplex
Audio
compression
AAC LC 8/16 kHz
G.711 PCM 8 kHz
G.726 ADPCM 8 kHz
Configurable bit rate
Audio input/
output
Built-in microphone, external microphone or line input, line output
Network
Security
Password protection, IP address filtering, HTTPS encryption,
IEEE 802.1X network access control, digest authentication,
user access log
Supported
protocols
IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP,
SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP,
IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, Pelco-D
System integration
Application
Programming
Interface
Open API for software integration, including VAPIX® from
Axis Communications available at www.axis.com
Intelligent video
Video motion detection, active tampering alarm, audio detection,
Gatekeeper
Alarm triggers
Intelligent video, temperature and external input
Alarm events
File upload via FTP, HTTP and email
Notification via email, HTTP and TCP
External output activation
Video buffer
96 MB pre- and post alarm
General
Processor and
memory
ARTPEC-3, 256 MB RAM, 128 MB Flash
Power
8 – 20 V DC max 11,2 W
20 - 24 V AC max 17,4 VA
Power over Ethernet IEEE 802.3af Class 3
Power supply not included
Connectors
RJ-45 10BASE-T/100BASE-TX PoE, terminal block for power,
I/O terminal block for two configurable inputs/outputs
3.5 mm mic/line in, 3.5 mm line out
RS-422/RS-485
Video out: 3x RCA Y/Pb/Pr (HD), 1x RCA Composite (SD)
Local storage
SD/SDHC memory card slot (card is not included)
Operating
conditions
0 - 45
º
C (32 - 113
º
F )
Humidity 20-80% RH (non-condensing)
Approvals
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024,
EN 61000-6-1, EN 61000-6-2, EN 60950-1, FCC Part 15, Subpart B,
Class B, VCCI, Class B ITE, C-tick AS/NZS CISPR 22, ICES-003, Class B
Weight
985 g (2.17 lb)
Included
accessories
Connector kits, Installation Guide, CD with installation tools,
recording software and User’s Manual, Windows decoder 1-user
license
More information is available at www.axis.com
