Axis Q1765-LE Datasheet

TechnicalSpecications-AXISQ1765-LENetworkCamera
Models
AXISQ1765-LENetworkCamera
Camera
Imagesensor
1/2.9"progressivescanRGBCMOS
Lens
f=4.7–84.6mm,F1.6–2.8,Autofocus,Automaticday/night
Horizontalangleofview:59°to4°
DayandnightAutomaticallyremovableinfrared-cutlter
Minimum
illumination
Color:0.5luxat30IREF1.6
B/W:0.04luxat30IREF1.6(0luxwithIRilluminationon)
Shuttertime
1/28000sto2s
Video
Video
compression
H.264MainlineandBaselineProles(MPEG-4Part10/AVC)
MotionJPEG
Resolutions
1920x1080(HDTV1080p)to320x180
Framerate
H.264/MotionJPEG:Upto30/25fps(60/50Hz)inallresolutions
VideostreamingMultiple,individuallycongurablestreamsinH.264andMotion
JPEG
Controllableframerateandbandwidth
VBR/CBRH.264
Imagesettings
Manualshuttertime,Compression,Color,Brightness,Sharpness,
Whitebalance,Exposurecontrol,Exposurezones,Backlight
compensation,Finetuningofbehavioratlowlight,Rotation,
Textandimageoverlay,3Dprivacymask,Day/nightshiftlevel,
Axis’CorridorFormat
Pan/Tilt/Zoom
18xopticalzoomand12xdigitalzoom
Presetpositions
Audio
AudiostreamingTwo-way
Audio
compression
AAC-LC8/16kHz,G.711PCM8kHz,G.726ADPCM8kHz
Congurablebitrate
Audio
input/output
Requiresmulti-connectorcable(notincluded)forexternal
microphoneinputorlineinputandlineoutput
Network
SecurityPasswordprotection,IPaddressltering,HTTPS
a
encryption,IEEE
802.1X
a
networkaccesscontrol,Digestauthentication,User
accesslog
Supported
protocols
IPv4/v6,HTTP,HTTPS
a
,SSL/TLS
a
,QoSLayer3DiffServ,FTP,
CIFS/SMB,SMTP,Bonjour,UPnP
TM
,SNMPv1/v2c/v3(MIB-II),
DNS,DynDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,RTCP,ICMP,
DHCP,ARP,SOCKS
Systemintegration
Application
Programming
Interface
OpenAPIforsoftwareintegration,includingVAPIX®
andAXISCameraApplicationPlatform;specicationsat
www.axis.com
AXISVideoHostingSystem(AVHS)withOne-ClickCamera
Connection.
ONVIFProleS,specicationatwww.onvif.org
Intelligentvideo
Videomotiondetection,ActiveGatekeeper,Activetampering
alarm,Audiodetection,AXISCameraApplicationPlatform
enablinginstallationofadditionalapplications
EventtriggersIntelligentvideo,Externalinput,Edgestorageevents
EventactionsFileupload:FTP,HTTP,networkshareandemail
Notication:email,HTTPandTCP
Externaloutputactivation
Videoandaudiorecordingtoedgestorage
Pre-andpost-alarmvideobuffering
DatastreamingEventdata
Built-in
installationaids
Pixelcounter
General
Casing
IP66-andNEMA4X-rated,impact-resistantaluminumenclosure
Color:whiteNCSS1002-B
Memory256MBRAM,128MBFlash
PowerPoweroverEthernetIEEE802.3af;max12.95W
8-28VDCmax15.2W,20-24VACmax22.0VA
Connectors
RJ4510BASE-T/100BASE-TXPoE
DCPowerconnector
Multi-connector(notincluded):2congurablealarm
inputs/outputs,micin,linemonoinput,linemonooutput(e.g.
toactivespeaker)
Edgestorage
MicroSD/microSDHC/microSDXCslotsupportingmemorycardup
to64GB(cardnotincluded)
Supportforrecordingtonetworkshare(network-attached
storageorleserver)
Operating
conditions
-40°Cto50°C(-40°Fto122°F)
Humidity10–100%RH(condensing)
Approvals
EN55022ClassB,EN61000-3-2,EN61000-3-3,
EN61000-6-1,EN61000-6-2,EN55024,EN50121-4,
FCCPart15SubpartBClassA,ICES-003ClassB,VCCIClassA,
C-tickAS/NZSCISPR22,KCCKN22ClassA,KN24,
IEC/EN/UL60950-22
Weight
1.8kg(4.0lb)includingthebracket
Included
accessories
Connectorkit,InstallationGuide,MiniCDwithinstallationtools,
RecordingsoftwareandUser’sManual,Windowsdecoder1-user
license,Allenkey
Optional
accessories
AXIST98A17-VESurveillanceCabinet
AXISMulticableAI/OAudio5m
Power:AXIST8120Midspan15W1-portorAXIST8129PoE
Extender
Mediaconverters:AXIST8640EthernetoverCoaxAdapterPoE+
orAXIST8604MediaConverterSwitch
Mounts:AXIST91A47PoleMount60mm–110mmorAXIS
T91A47PoleMount110mm-400mmorAXIST94P01BCorner
Bracket
Video
management
software
AXISCameraCompanion(included),AXISCameraStation
andvideomanagementsoftwarefromAxis’Application
DevelopmentPartners(notincluded).Formoreinformation,see
www.axis.com/products/video/software
Warranty
Axis3–yearwarranty,seewww.axis.com/warranty
a.ThisproductincludessoftwaredevelopedbytheOpenSSLProjectforuseinthe
OpenSSLToolkit.(www.openssl.org),andcryptographicsoftwarewrittenbyEric
Young(eay@cryptsoft.com).
Moreinformationisavailableatwww.axis.com
www.axis.com
©2013AxisCommunicationsAB.AXISCOMMUNICATIONS,AXIS,ETRAX,ARTPECandVAPIXareregisteredtrademarksor
trademarkapplicationsofAxisABinvariousjurisdictions.Allothercompanynamesandproductsaretrademarksorregistered
trademarksoftheirrespectivecompanies.Wereservetherighttointroducemodicationswithoutnotice.
54476/EN/M1.4/102013

Axis Q1765-LE Specifications

Camera

image sensor	1/2.9" progressive scan RGB CMOS
lens	f=4.7–84.6 mm, F1.6–2.8, Autofocus, Automatic day/night
horizontal angle of view	59° to 4°

Video

shutter time	1/28000 s to 2 s
video resolutions	1920x1080 (HDTV 1080p) to 320x180
frame rate	Up to 30/25 fps (60/50 Hz) in all resolutions

Operating Environment

operating temperature	-40 °C to 50 °C (-40 °F to 122 °F)
humidity	10–100% RH (condensing)
casing	IP66- and NEMA 4X-rated, impact-resistant aluminum enclosure

Power

power over ethernet	IEEE 802.3af; max 12.95 W
power input	8-28 V DC max 15.2 W
power input AC	20-24 V AC max 22.0 VA

Memory and Storage

memory	256 MB RAM, 128 MB Flash
edge storage	MicroSD/microSDHC/microSDXC slot up to 64 GB
recording support	network share (NAS or file server)

Weight and Dimensions

weight with bracket	1.8 kg (4.0 lb)
optical zoom	18x
digital zoom	12x
