Axis T23 User Manual

tower, canvas and
accessories
ThetoweronallAxismodelsistheGreySkull.The
GreySkullcanberaisedtoitsfullheightforextraor-
dinaryboatingenjoyment,orloweredfortowingand
storage,orforbridgeclearancewhileonthewater.
Lowering the Tower:
Step 1:Priortoloweringthetower,fold
 anyboardracksinward.
Step 2:Slidethehelmseatall
thewayforwardand
rotate the seat so that
itfacesaft.
Step 3: Oneachinteriorsideof
thetowerlegsaretwo
knobs.Onthehelm
(driver’sside)ofthe
tower,simplyunscrew
bothknobs.Place
theknobsinasecure
location(wesuggest
usingthesameloca-
tionrepeatedlysothe
knobswillbeeasyto
nd),suchastheglove
boxoracupholder.
Step 4:Aftertheknobsare
removed,foldthe
Axislogoplateinward
untilitisinthefully
loweredposition.(It
willstillbeattachedto
thetowerbase.)
Step 5:  Ontheoppositeside,
whileholdingtheoverheadhoopbartosteadyit,un-
screwbothknobsandplaceinasecurelocation.Make
sureyouholdontothetopbartopreventitfromfalling
incasethesideplacecomesloose.
Step 6:  Aftertheknobsareremoved,donotrotatetheAxislogo
plateyet.Slightlylifttheoverheadhoopbartorelieve
pressureontheleg.
Step 7:  Withyourotherhand,nowfoldtheAxislogoplatein-
warduntilitisinthefullyloweredposition.(Itwillstillbe
attachedtothetowerbase.)
Step 8: Gentlylowerthetowertowardtheaftuntilitreachesitslowestlevel.
Axis
Owners
Manual
2019
Page 96
Step 1
Step 2
Steps 3 & 5
Steps 4 & 6
Step 8
