High PoE Midspan and Splitters Installation Guide Page 5
ENGLISH
Specifications
Environmental
Electrical
Ethernet interface
Mode Temperature Humidity
Operating 0 - 40°C
32 to 104°F
10 to 90% (no condensation allowed)
Storage -20 to 70°C
-4 to 158°F
Input voltage 100 -240VAC (50-60 Hz)
Input current 0.8A (max)
Maximum Available Output Power 30W
Nominal Output Voltage 52 to 56V DC
Input (Data In): RJ45 female socket
Ethernet 10/100/1000Base-T
Output (Data & Power Out): RJ45 female socket
Ethernet 10/100/1000Base-T, plus 48 VDC
Wiring Data provided over pairs 1/2 and 3/6 for 10/100 Ethernet, over all four pairs
for Gigabit Ethernet
Power provided over spare pairs 4/5(+) and 7/8(-).
Network cable Category 5 (or higher), foiled twisted-pair (FTP) cable recommended.
