AXIST8415WirelessInstallationTool
6
WLANindicator
7
Resetbutton
8
MainUnit
9
BatteryChargerconnector
10
Battery
11
Label(networksettings)
1
Charger
2
Chargermaleconnector
3
ChargerLED
4
Powercordplug(EU)
5
Powercordplug(US)
6
Powercordplug(UK)
7
Powercordplug(AU)
Networkconnector
RJ45Ethernetconnector.
RJ45EthernetconnectorwithPoweroverEthernetPlus(PoE+).
NO NO
NO
TICE TICE
TICE
Duetolocalregulationsortheenvironmentalandelectricalconditionsinwhichtheproduct
istobeused,ashieldednetworkcable(STP)maybeappropriateorrequired.Allcables
connectingtheproducttothenetworkandthatareroutedoutdoorsorindemanding
electricalenvironmentsshallbeintendedfortheirspecicuse.Makesurethatthenetwork
devicesareinstalledinaccordancewiththemanufacturer’sinstructions.Forinformation
aboutregulatoryrequirements,seeElectromagneticcompatibility(EMC)onpage2.
