3
Quantity Item Part
1 No ATDP13B Small Bench Pillar Drill A
Quantity Item Part
1 No ATDP17F Floor Pillar Drill C
Quantity Item Part
1 No ATDP16B Medium Bench Pillar Drill B
Quantity Item Part
1 No ATDP20F Floor Pillar Drill D
Model Number ZQJ4116K
Model Number ZQJ4125QK
Model Number ZQJ4119K
Model Number ZQJ4132K
A B C D
1 No Pillar for drill head complete with mounting
flange, rise and fall rack and retaining ring 1
1 No Drill table extension bracket arm 2
1 No Pillar drill head 3
1 No Drill table square (Small) 4 (102552 ONLY)
1 No Drill table square (Medium) 4a (102553 ONLY)
1 No Drill table square (Large) 4b (102554 ONLY)
1 No Base (Small,Medium, Large) 5 (102552-102553-102554 ONLY)
1 No Chuck guard assembly mounting bracket 6
1 No Chuck guard assembly 7
2 No Lift and shift handle clamps for the rise
and fall mechanism, drill table 8
1 No Lever feed handle assembly with M8x50mm cap head screw 9
1 No Crank handle for table rise and fall mechanism (small) 10 (102552-102553-102554 ONLY)
1 No Crank handle for table rise and fall mechanism (Large) 10 (102555 ONLY)
1 No Keyless chuck 3-16mm 11
1 No Morse taper arbor for chuck assembly 12
1 No Pulley cover knob & Phillips screw 13
1 No Morse taper drift 14
3 No Hex Keys 3-5-6mm 15
4 No M10x25mm + washers 16 (102552-102553-102554 ONLY)
4 No M6x11mm Button head Phillips screws 17
2 No M5x14mm Button head Phillips screws 18
Box Containing:
THE ATDP20F IS EXTREMELY HEAVY & COMES
LARGELY ASSEMBLED FOR SAFETY AND
TRANSPORT!
To Next Page
