Axminster ATDP13B - Specification

Specification
7
Code 102552
Model ATDP13B
Power 550W (230V 1ph)
Speed Range (12) 210-2,580rpm
Throat 165mm
Taper 2MT
Chuck Cap/Type 16mm keyless
Chuck Travel 80mm
Max Chuck to Table 340mm
Max Chuck to Base 530mm
Diameter of Column 70mm
Table Size 260 x 260mm
Table Tilt 45˚ - 0 - 45˚
Base Size 420 x 250mm
Overall Size L x W x H 640 x 370 x 820mm
Weight 63kg
Code 102554
Model ATDP17F
Power 750W (230V 1ph)
Speed Range (12) 120-2,580rpm
Throat 216mm
Taper 3MT/B16
Chuck Cap/Type 16mm keyless
Chuck Travel 80mm
Max Chuck to Table 700mm
Max Chuck to Base 1,150mm
Diameter of Column 80mm
Table Size 345 x 345mm
Table Tilt 45˚ - 0 - 45˚
Base Size 520 x 320mm
Overall Size L x W x H 750 x 430 x 1,650mm
Weight 108kg
Code 102553
Model ATDP16B
Power 650W (230V 1ph)
Speed Range (12) 120-2,580rpm
Throat 178mm
Taper 2MT
Chuck Cap/Type 16mm keyless
Chuck Travel 80mm
Max Chuck to Table 325mm
Max Chuck to Base 500mm
Diameter of Column 80mm
Table Size 290 x 290mm
Table Tilt 45˚ - 0 - 45˚
Base Size 450 x 270mm
Overall Size L x W x H 670 x 360 x 1,020mm
Weight 82kg
Code 102555
Model ATDP20F
Power 1100W (230V 1ph)
Speed Range (12) 150-2,700rpm
Throat 254mm
Taper 3MT
Chuck Cap/Type 16mm keyless
Chuck Travel 120mm
Max Chuck to Table 540mm
Max Chuck to Base 1,090mm
Diameter of Column 92mm
Table Size 475 x 425mm
Table Tilt 45˚ - 0 - 45˚
Base Size 580 x 450mm
Overall Size L x W x H 860 x 610 x 1,710mm
Weight 143kg
