Axminster SBW3501B - Page 32

Parts Breakdown/List
32
103 150031 PIN 2
104 Sf059200 PAN HEAD BOLT W/FLANGE M5x8 5
105 130043 RIGHT COVER 1
106 150010 ADJUSTING NUT 4
107 Ss080801 ADJUSTING SCREW M8x1.0x40 4
108 150014 THUMBSCREW M6x12 1
109 150206 LOWER SUPPORT BRACKET POST 1
111 135011 POINT 1
112 Sh069300 HEX HEAD BOLT M6x12 2
113 Wf083030 FLAT WASHER M8xO30 2
114 Ws080000 SPRING WASHER M8 2
115 Sr080500 SOCKET CAP BOLT M8x25 2
116 170507 BRUSH 1
117 Sf059200 PAN HEAD BOLT W/FLANGE M5x8 1
118 Sh080600 HEX HEAD BOLT M8x30 3
119 Ws080000 HEX HEAD WASHER M8 3
120 130021 TRUNNION SUPPORT BRACKET 1
121 Sh081600 HEX HEAD BOLT M8x80 1
122 Nh081300 NUT M8 1
123 110049 POINTER 1
124 Sp059100 PAN HEAD BOLT M5x6 1
125 100030 LOCK KNOB M10 2
126 199037 TABLE INSERT 1
127 130045 TABLE PIN 1
128 170749 TABLE 1
129 Sh101003 HEX HEAD BOLT M10x50 2
130 100041 TRUNNION CLAMPSHOES 2
131 100042 TRUNNION 2
132 100051 SCALE 1
133 Sg069300 HEX HEAD FLANGE BOLT M6x12 6
134 130024 SAW BLADE 2553 x 10x0.5mm 1
135 Sf059200 PAN HEAD BOLT W/FLANGE M5x8 4
136 Sp040200 PAN HEAD BOLT M4x10 2
137 Sp059300 PAN HEAD BOLT M5x12 2
138 We050000 STAR WASHER (EXTERNAL) M5 2
139 Nh050800 NUT M5 4
140 Ic130003 POWER CORD 1
141 Im130002 MOTOR CORD 1
142 Sf059200 PAN HEAD BOLT W/FLANGE M5x8 2
143 998621 STRAIN RELIEF 2
144 135056 PLATE 1
145 130013 SWITCH PLATE 1
146 994542 SWITCH 1
148 Ab100083 MITER GAUGE (ASM) 1
100083 MITER GAUGE 1
