Axon Fleet 2 Camera System User Manual
Axon Enterprise, Inc. Page 11 of 22
Operation LED – Shows the camera’s current operating mode.
When you turn the camera ON, the Operation LED turns solid red until the system is ready to
use. Then the Operation LED blinks green (BUFFERING mode) and the Battery LED goes out.
Operating Mode Operation LED
Recording Blinking red
Buffering Blinking green
Booting up/powering down Solid red
Power switch – Turns the camera’s power ON or OFF. When the camera’s power is turned
ON, the red portion is exposed. When the camera power is turned OFF, the red portion is
covered from view. The camera might take several additional seconds to close out of the
video when it is powered OFF before stopping an event.
EVENT button – Used to start and stop recording. Press once to start. Press once again to
stop.
Speaker – Provides audio notifications.
Function button – Used to mute the device and to add markers to the video as it is
recorded.
Axon Fleet Power Unit
The Axon Fleet system uses the vehicle’s electrical system as a power source. If the vehicle’s
ignition is shut off, the battery in the Axon Fleet power unit supplies power to the camera so
it can keep recording. With a fully charged power unit battery, the camera can record up to 4
hours without the engine running. The battery will begin recharging when the engine is
turned back on. It may take over 3 hours for a depleted battery to fully recharge.
