Tracking output
A tracking output is provided by the ASV12. This output provides
a timing pulse for use with other Axon Synapse devices, e.g. for
Audio Synchronisation with a DIO24.
Back planes
The ASV12 can be used with the BPL01 back plane.
Miscellaneous
The ASV12 cards fit into the Axon SFR04 & SFR18 rack.
LED’s on the front of the board indicate the presence Video
Reference, Input signal, Connection & Processor Errors.
The ASV12 can be controlled by Axon Synapse set-up software.
