Synapse Setup
Software
Synapse Setup Software can be used to change the settings of
Synapse modules from a PC, either locally or remotely. The
software enables communication based on TCP/IP between the
Setup PC and Synapse frames/modules.
Each Synapse frame is addressed through its rack controller’s
unique IP address, giving access to each module, its menus and
adjustment items. The Synapse Setup software has access to data
contained within the Synapse module and displays it on a GUI.
The software has an intuitive structure following that of the
module that it is controlling.
Having selected the desired Frame and Module from the GUI
Synapse Network View, select the menu item that you wish to
open. Opening the menu item gives a complete list of available
properties with their associated Value.
For example to change a setting e.g. SDI-Format, select SDI-
Format form the list of settings by ‘double clicking’ to open a
dialogue box. The dialogue box allows parameters to be changed
or set to default value. On completion close the dialogue box.
Menu Structure
Example
Slot Module Item Parameter Setting
▲
▲
S02 Identity
▲ ▲
S01 SFS10
►
Settings
►
SDI-
Format
►
Auto
▼ ▼ ▼ ▼
S00 RRC18 Status Mode 625
▼ ▼ ▼
Events Ref-Input 525
▼
H-Delay
▼
▼
REMARK: Further information about Front Panel Control and
Synapse Setup Software can be obtained from the RRC18 and
RRC04 operational manuals.
