6 Status Menu
Introduction
The status menu indicates the current status of each item listed
below.
Analog-Inp
This status item indicates the presence of a valid analog video
signal at the input. Analog-Inp indicates if an input signal is
NA (not available) or Present.
Reference
This status item recognises a valid reference input on the chosen
reference input. Status is not fed back when there is no input.
Reference indicates if a reference input is NA (not available)
or Present.
Format-Det
625 and 525 standards can be detected as the valid input signal
format, 625/50 and 525/60 are recognised as valid inputs.
Audio-CH_A1
Audio-CH_A1 displays the status of audio channel A1. The
status can be NA (not available) or Ok.
Audio-CH_A2
Audio-CH_A2 displays the status of audio channel A2. The
status can be NA (not available) or Ok.
Audio-CH_A3
Audio-CH_A3 displays the status of audio channel A3. The
status can be NA (not available) or Ok.
Audio-CH_A4
Audio-CH_A4 displays the status of audio channel A4. The
status can be NA (not available) or Ok.
Audio-CH_B1
Audio-CH_B1 displays the status of audio channel B1. The
status can be NA (not available) or Ok.
Audio-CH_B2
Audio-CH_B2 displays the status of audio channel B2. The
status can be NA (not available) or Ok.
Audio-CH_B3
Audio-CH_B3 displays the status of audio channel B3. The
status can be NA (not available) or Ok.
