21
8 LED Indication
Error LED
The error LED indicates an error if the internal logic of the
ASV12 card is not configured correctly or has a hardware failure.
Input LED
This LED indicated the presence of a valid video signal on the
input.
Reference LED
Indicated the presence of a valid reference signal on the selected
reference input connector (ref-1 or ref-2). See section 5 Ref Input.
Connection LED
This LED illuminates after the card has initialised. The LED
lights for 0.5 seconds every time a connection is made to the card.
