The HDR07 Card
Introduction
The AXON HDR07 is a High Definition distribution amplifier
with re-clocking functionality.
Inputs and Outputs
The HDR07 is a single input, seven output distribution amplifier.
SD SDI Compatible
The HDR07 is compatible with a range of Standard Definition SDI
input signals.
Back planes
The HDR07 can be used with the BPH07 backplanes.
Features
 Compatible with:
 143 Mbit/s
 177 Mbit/s
 270 Mbit/s
 360 Mbit/s
 540 Mbit/s
 1485 Mbit/s
 Inverting and non inverting outputs
 Bypass function of the reclocker for non-standard
frequencies
 Full control and status monitoring through the front panel
of the SFR04/SFR08/SFR18 frame and the Ethernet port
(ACP)
 Optional 1 fiber input (replacing 1 SDI input) or 1 fiber
output (replacing 1 SDI output) on I/O panel

Axon Synapse HDR07 Specifications

General

Brand	Axon
Model	Synapse HDR07
Category	Amplifier
Language	English
