14
9 Block Schematics
HDR07
HDR07
RACK
CONTROLLER
HD/SD-SDI IN
EQ
HD/SD-SDI OUT 1
RECLOCKER
+
µP
HD/SD-SDI OUT 2
-
HD/SD-SDI OUT 3
+
HD/SD-SDI OUT 4
-
HD/SD-SDI OUT 5
+
HD/SD-SDI OUT 6
-
HD/SD-SDI OUT 7
+
INTERNAL SYNAPSE BUS
